For professional contractors who demand superior performance and impeccable precision in difficult environments, the Rippa R1…
| Type | Tracked ZTS mini excavator |
| Operating weight | 1.300 kg / 2.866 lb |
| Engine | Kubota D722 |
| Maximum power | 10,2 kW / 13,7 CP |
| Number of cylinders | 3 |
| Hydraulic system pressure | 20 MPa |
| Hydraulic control type | Pilot: joystick |
| Bucket capacity | 0,03 m³ / 1,1 ft³ |
| Maximum digging radius | 3.346 mm / 131,7 in |
| Maximum digging depth | 1.843 mm / 72,6 in |
| Maximum digging height | 3.011 mm / 118,6 in |
| Maximum dumping height | 2.238 mm / 88,1 in |
| Maximum boom swing angle | 105° |
| Track width range | 750–990 mm / 29,5–39 in |
| Transport dimensions (L × W × H) | 2.114 × 750 × 2.289 mm |
| Attachment coupler | Quick hydraulic (standard) |
| Hydraulic thumb (thumb clamp) | Included as standard |
| Display | Digital monitor: diagnostics and operating hours |
There are jobs a standard excavator cannot do: narrow urban sites, residential yards with limited access, spaces between buildings where the counterweight of a conventional machine would cause damage on every slew. That is where a ZTS mini excavator comes into play.
The Rippa R13 Professional model takes the Zero Tail Swing concept to the level of a fully equipped professional machine, with a Kubota engine, a pilot hydraulic system and standard features that are paid options on competitors.
With an operating weight of 1.300 kg and a digging depth of 1.843 mm, this ZTS mini excavator covers the wide range of utility works, light foundations, landscaping and selective demolition, anywhere in Romania, including in areas where access with large machines is physically impossible. Why ZTS matters: the real on-site advantage of the Rippa R13 mini excavator
• The counterweight never exceeds the track width: during a full 360° slew, no part of the machine extends beyond the track footprint. You work 10 cm from a wall without risk of collision.
• Ideal for urban and residential spaces: alleys, interior yards, basements, areas with pedestrian traffic. A ZTS mini excavator operates where long-tail machines are prohibited or dangerous.
• Increased safety on active sites: eliminating the risk of striking to the rear significantly reduces incidents in crowded areas with personnel or other equipment nearby.
• Higher productivity in narrow spaces: the operator can freely slew the house without constantly checking what is behind, focusing exclusively on the precision of the dig.
Technical specifications: ZTS mini excavator Rippa R13 Professional
| Parameter | Value |
|---|---|
| Model | Rippa R13 Professional (R13-PRO) |
| Type | Tracked ZTS mini excavator |
| Operating weight | 1.300 kg / 2.866 lb |
| Engine | Kubota D722 |
| Maximum power | 10,2 kW / 13,7 CP |
| Number of cylinders | 3 |
| Hydraulic system pressure | 20 MPa |
| Hydraulic control type | Pilot: joystick |
| Bucket capacity | 0,03 m³ / 1,1 ft³ |
| Maximum digging radius | 3.346 mm / 131,7 in |
| Maximum digging depth | 1.843 mm / 72,6 in |
| Maximum digging height | 3.011 mm / 118,6 in |
| Maximum dumping height | 2.238 mm / 88,1 in |
| Maximum boom swing angle | 105° |
| Track width range | 750–990 mm / 29,5–39 in |
| Transport dimensions (L × W × H) | 2.114 × 750 × 2.289 mm |
| Attachment coupler | Quick hydraulic (standard) |
| Hydraulic thumb (thumb clamp) | Included as standard |
| Display | Digital monitor: diagnostics and operating hours |
Pilot hydraulic system: what it means in practice for the R13 operator
Most mini excavators in the 1-tonne class use direct mechanical controls: the levers physically actuate the hydraulic spools through cables or rods. On this ZTS mini excavator, the controls are pilot hydraulic: the joysticks send low-pressure hydraulic signals that activate the main valves. The difference in the field is significant.
“Most mini excavators in the 1-tonne class use direct mechanical controls: the levers physically actuate the hydraulic spools through cables or rods.”
• Minimal physical effort: the joysticks move easily, with no mechanical resistance. An operator who runs a machine with pilot hydraulics for 8 hours tires substantially less than one with mechanical controls.
• Superior precision: small joystick movements produce proportional and smooth movements of the arm. Critical for precise grading, work near existing infrastructure or digging at controlled depth.
• Simultaneous control of multiple functions: the operator can simultaneously command the house slew, the arm movement and the auxiliary function (thumb, breaker) without loss of speed or precision.
Standard features that set the Rippa R13 Professional apart
The term "Professional" in the name is not marketing; it reflects the features included in the base price of this ZTS mini excavator, which other manufacturers sell as optional accessories:
• Standard hydraulic thumb (thumb clamp), allows gripping and handling irregular objects: boulders, logs, construction debris, pipes. It turns the excavator into a material-handling machine at no additional cost.
• Standard hydraulic quick coupler: changing the bucket or attachment (breaker, grading bucket, auger) is done from the cabin in a few seconds. No getting down, no tools, no time lost on site.
• Digital monitor: real-time display with system diagnostics, operating hours, service warnings. Data accessible directly from the seat, without opening the hood.
The combination of compact dimensions, ZTS design and professional features makes the R13 a ZTS mini excavator.
In residential construction and urban utility works, this ZTS mini excavator excels at digging trenches.
Weight 1,300 kg / 2,866 lb
• Kubota D722 engine: a 3-cylinder engine recognised in the industry for exceptional reliability and reduced maintenance costs. Spare parts available in Romania.
• Hydraulic pressure 20 MPa: 25–33% higher than the entry-level models in the 1-tonne class. It translates directly into greater digging force and superior performance in compact or clay soils.
Applications: where the Rippa R13 ZTS mini excavator works efficiently
The combination of compact dimensions, the ZTS design and the professional features makes the R13 a versatile ZTS mini excavator, with an unusually wide range of applicability for its weight class.
In residential construction and urban utility works, this ZTS mini excavator excels at digging trenches for water, gas and sewer networks in areas with limited access, at foundations for light structures and fences, at selective demolition and at clearing debris in narrow spaces. The 750 mm transport width allows access through standard yard doors.
Landscapers and green-space maintenance firms choose a Rippa R13 ZTS mini excavator for planting large trees, drainage, terrain shaping and the demolition of concrete elements in gardens or parks, work that previously required intensive manual labour or much larger machines that were destructive to adjacent surfaces. Frequently asked questions about the Rippa R13 Professional ZTS mini excavator
What exactly does ZTS mean and how is it verified in the field?
An authentic ZTS mini excavator has the rear counterweight designed so that in no slew position does it exceed the outer line of the tracks. On the R13-PRO it is verified simply: with the machine stationary, you slew the house 360° and observe that no element at the rear passes beyond the edge of the tracks. Pseudo-ZTS models or those with "reduced tail swing" have partial overhang; the R13 does not. How easily is the R13 transported between different sites?
The transport dimensions of this ZTS mini excavator are 2.114 × 750 × 2.289 mm, with a weight of 1.300 kg. It loads without problems onto a standard 2-tonne trailer or onto the platform of a light trailer. It requires no special transport, oversize permits or dedicated lifting equipment. Does the Kubota engine require specialised service?
No. The Kubota D722 engine is one of the most widespread small diesel engines in Europe, with a well-represented service and parts distributor network in Romania. Service intervals are standard (oil, filters), achievable in any mechanical workshop experienced with machinery. UZINEX provides the spare parts specific to the R13 model in its own stock. Details on the UZINEX technical support page. Can the R13 be used with attachments from other brands?
The standard hydraulic quick coupler of this ZTS mini excavator is compatible with attachments for the 1–1,5 tonne class, including breakers, grading buckets, augers and the hydraulic rake. Exact compatibility depends on the attachment brand; UZINEX engineers can confirm compatibility for the specific attachments you own or intend to purchase. Is it eligible for financing or EU programmes?
Yes. UZINEX is a member of the Enterprise Europe Network and the Chamber of Commerce and Industry, with experience in supplying machinery for EU-funded and PNRR projects. Complete technical documentation for public or private procurement files is provided on request, including for SEAP/SICAP. Why UZINEX for the Rippa R13 ZTS mini excavator
Purchasing a ZTS mini excavator involves more than the machine price: it involves parts availability, technical support and the certainty that the machine starts on the first turn of the key and the day after you receive it. UZINEX fully covers this equation:
• 60-month warranty: extended coverage compared to the 12-month market standard, for a ZTS mini excavator in intensive professional use.
• Transport and commissioning included: delivery to your premises, full testing and operator training on the actual machine, not on paper.
• Spare parts in stock: components for the R13 available immediately. No weeks of waiting for imported parts.
• National technical support 24–48 hours: a network of service technicians at national level, with a guaranteed response time.
• AI-powered manuals: interactive documentation for fast diagnosis, accessible from any device directly on site.
• Attachment selection consultancy: if you purchase the R13 for specific applications (narrow trenches, work in enclosed spaces, landscaping), UZINEX engineers recommend the optimal attachment configuration. Free technical consultancy here.
A Rippa R13 Professional ZTS mini excavator is the right investment for construction companies, utility contractors and landscapers who frequently work in urban and residential spaces where dimensions and precision matter as much as raw power.
