The Monde mini-excavator drum screening bucket is the particle-size sorting attachment with a perforated rotating drum designed for mini-excavators and compact excavators — the solution for sorting soil, gravel and construction rubble directly on site, without separate sorting plants or transport to a fixed station.
Weighing 158 kg with a capacity of 0.33 m³, the Monde mini-excavator drum screening bucket mounts via a quick coupler on any mini-excavator and turns the existing machine into a mobile sorting station with a rotating drum 610 mm in diameter.
The Monde mini-excavator drum screening bucket operates at 120–150 bar and requires an oil flow of 20–30 L/min — parameters compatible with the standard auxiliary circuits of mini-excavators and compact excavators equipped with a quick coupler. The drum rotating at 35–60 rpm processes the material continuously, separates the fine fractions through the calibrated drum perforations and retains the coarse fractions for separate discharge. Construction from Q345 and NM400 with CE and ISO9001 certification ensures durability and documentary compliance for public tenders. Technical specifications — Monde mini-excavator drum screening bucket
| Parameter | Value |
|---|---|
| Weight | 158 kg |
| Bucket capacity | 0,33 m³ |
| Rotating drum diameter | 610 mm |
| Drum rotation speed | 35–60 rpm |
| Working pressure | 120–150 bar |
| Required oil flow | 20–30 L/min |
| Main material | Q345, NM400 |
| Bucket type | Rotary with perforated drum |
| Coupling type | Quick coupler |
| Standard colour | Yellow (customisable on request) |
| Certifications | CE, ISO9001 |
| Main applications | Construction, road works, agriculture, landscaping |
UZINEX engineers confirm the compatibility of the mini-excavator drum screening bucket with your specific machine model and with the particle size required by your application — free technical consultancy available. Main advantages of the Monde mini-excavator drum screening bucket
• Rotating drum Ø610 mm, 35–60 rpm — continuous sorting — the Monde mini-excavator drum screening bucket sorts by particle size through a perforated drum rotating at 35–60 rpm. The fine fractions pass through the perforations as usable sorted material; the coarse fractions are retained and discharged separately. This principle eliminates manual sorting and repeated passes with the bucket.
• 158 kg — sized for mini-excavators and compact excavators — the Monde mini-excavator drum screening bucket weighs 158 kg, a compact format that fits within the lifting capacity of mini-excavators and compact excavators available on residential construction, landscaping and road-works sites. The low weight eliminates the need for a medium or large excavator solely for the sorting operation.
• Capacity 0.33 m³ — optimal volume for working in confined spaces — the 0.33 m³ capacity of the Monde mini-excavator drum screening bucket is calibrated for fast load-sort-discharge cycles in areas with limited access — gardens, narrow urban sites, spaces inside buildings under renovation, channels and trenches. A larger volume would be unnecessary for these applications and would increase the weight of the attachment without justification.
• 120–150 bar, 20–30 L/min — standard mini-excavator parameters — the Monde mini-excavator drum screening bucket operates at 120–150 bar with a flow of 20–30 L/min — specifications at the lower limit of the auxiliary circuits of modern compact excavators. This low hydraulic requirement makes the bucket compatible with a wide range of mini-excavators without exhausting the available auxiliary circuit.
• Quick coupler — mounting and dismounting in less than a minute — the Monde mini-excavator drum screening bucket is equipped with a quick coupling compatible with standard quick-coupler systems. The operator mounts and dismounts the bucket directly from the mini-excavator cab in less than a minute, alternating between the mini-excavator drum screening bucket and the standard digging bucket or other attachments depending on the work phase.
• Operation with wet and dry materials — the Monde mini-excavator drum screening bucket efficiently processes both dry soil, sand and gravel and wet clay soil, sludge and vegetable residues with high moisture content. The continuous rotation of the drum prevents the perforations from clogging with clay material — a frequent problem with static screening grids used with wet material.
• Q345 + NM400, CE and ISO9001 certification — the Monde mini-excavator drum screening bucket is built from Q345 on the load-bearing structure and NM400 on the drum wear surfaces, with CE and ISO9001 certification included in the delivery documentation. The certifications are required for eligibility in public tenders and EU-funded projects.
• Customisation of dimensions and colour — the Monde mini-excavator drum screening bucket is available in standard yellow with custom colour options on request. The dimensions of the drum and the perforations can be configured for the specific particle size required by your application.
• 60-month UZINEX warranty — spare parts for the drum and wear components in stock at Iași, guaranteed national technical support within 24–48 hours.
Main applications of the mini-excavator drum screening bucket
Separation and management of construction and demolition waste on residential sites is the central application of the Monde mini-excavator drum screening bucket on the Romanian market. Concrete, brick, stoneware and mortar rubble from renovations and partial demolitions is processed directly on site — the sorted fine material is reused as fill or disposed of as inert waste, while the large pieces are separated for distinct removal. Everything is done with the mini-excavator already present on site.
Road works and local infrastructure — rehabilitation of communal roads, laying cables and pipes, building private accesses — frequently require the particle-size sorting of gravel and sand to obtain the fractions needed for the laying bed and compaction. The Monde mini-excavator drum screening bucket performs this sorting on the spot, eliminating the cost and logistics of purchasing pre-sorted material from a quarry.
Agriculture and landscaping — preparing topsoil, separating stones and roots from soil, preparing compost and growing substrate — are frequent applications of the Monde mini-excavator drum screening bucket on private properties, farms and urban development projects. A mini-excavator equipped with the drum screening bucket directly produces sorted fine soil usable as topsoil without additional manual intervention.
Landscaping and the development of green spaces in urban areas — parks, public gardens, pedestrian paths — are applications where the compact size of the Monde mini-excavator drum screening bucket is essential: access to tight spaces, working without damaging the adjacent pavements and structures, and producing a fine sorted material usable directly as a planting substrate. The mini-excavator drum screening bucket vs. the shredder screening bucket — different principles
The Monde mini-excavator drum screening bucket and the Monde shredder screening bucket are sorting attachments with fundamentally different operating principles and usage profiles.
The Monde mini-excavator drum screening bucket performs pure particle-size sorting — the material is screened through the perforations of the rotating drum without being crushed or having its particle size altered. The material that passes through the drum has the particle size dictated by the size of the perforations; the material that does not pass through is returned as an unaltered coarse fraction. This is the correct principle for applications where the material must be sorted, not transformed.
The Monde shredder screening bucket performs crushing + sorting simultaneously through rotary shredders — the material is both shredded and sorted, reducing the particle size during the screening process. This is the solution when the input material is too coarse to pass directly through the screen and requires pre-fragmentation.
On medium and large excavators equipped with a Monde DEHN quick coupler, the mini-excavator drum screening bucket can be alternated with the standard bucket or other attachments in less than a minute. Frequently asked questions about the Monde mini-excavator drum screening bucket
What particle size does the Monde mini-excavator drum screening bucket produce?
The particle size of the sorted material depends on the size of the drum perforations — configurable at the quotation stage according to the application. Larger perforations are used for fill soil; smaller perforations are used for fine vegetable substrate. UZINEX engineers configure the perforation size for the particle size required by your specific application. Does the Monde mini-excavator drum screening bucket require an additional hydraulic circuit?
Yes — the rotating drum of the Monde mini-excavator drum screening bucket is hydraulically driven and requires an auxiliary circuit at 120–150 bar with a flow of 20–30 L/min. Most modern mini-excavators have an auxiliary circuit within these parameters. UZINEX verifies compatibility with your machine model at the quotation stage. Is the mini-excavator drum screening bucket compatible with any quick coupler?
The Monde mini-excavator drum screening bucket is designed for a standard quick coupling. Compatibility with the specific quick coupler of your machine is confirmed at the quotation stage — the adapter geometry can be configured for the various quick-coupling systems on the market. Is the mini-excavator drum screening bucket eligible for public tenders?
Yes. The Monde mini-excavator drum screening bucket is CE and ISO9001 certified — the quality documents required in the technical specifications of public procurement. UZINEX provides the complete documentation on delivery. The product can be added directly in SEAP/SICAP. UZINEX is a member of the Enterprise Europe Network. Why UZINEX for the Monde mini-excavator drum screening bucket
The mini-excavator drum screening bucket turns a compact machine into a mobile particle-size sorting station — productivity and the quality of the sorted material depend on correctly configuring the drum perforations for the specific application.
• Drum perforation configuration included — UZINEX configures the mini-excavator drum screening bucket to the particle size and material type required by your specific application.
• Hydraulic and quick-coupler compatibility check — the auxiliary circuit and the quick-coupling system confirmed for your mini-excavator before delivery.
• CE + ISO9001 certification guaranteed — complete documentation for public tenders and EU-funded projects.
• 60-month warranty — extended coverage for the Monde mini-excavator drum screening bucket under use on construction, landscaping and agriculture sites.
• Transport and installation included — delivery to destination, installation on the mini-excavator, hydraulic adjustments and operator training included.
• Drum spare parts permanently in stock at Iași — wear components available immediately.
• National technical support within 24–48 hours — a network of technicians with nationwide coverage and a guaranteed response time.
• Financing options — leasing and credit available on the UZINEX credit and leasing page.
The Monde mini-excavator drum screening bucket available through UZINEX — 158 kg, 0.33 m³, rotating drum Ø610 mm, 35–60 rpm, 120–150 bar, 20–30 L/min, Q345+NM400, quick coupler, CE+ISO9001 certified, 60-month warranty, transport and installation included throughout Romania.
