Building on the mining bucket, our engineers add extra steel plates welded to the bottom of the bucket, so…
| Compatible excavators | 6–70 tonnes |
| Capacity | 0,5 m³–4 m³ (model-dependent) |
| Weight | 800–1.400 kg (size-dependent) |
| Structural materials | Q345B, Q460, Hardox 400/500, NM360/450, WH60A |
| Bottom design | Double-radius: extended heel clearance, reduced friction |
| Extra wear plates | Yes: outer bottom, side corners, heel |
| Compatible makes | CAT320, PC1250, ZX1200, ZX1900 and other 6–70t models |
| Customization | Dimensions, widths, heights and openings on request |
| Main applications | Mining, industrial quarries, heavy structural demolition |
The Monde heavy duty excavator bucket is the highest wear-resistance digging attachment in the Monde range, engineered for the extreme conditions of mining, industrial quarries and heavy structural demolition, where an ordinary bucket cannot sustain acceptable maintenance intervals.
With capacities from 0,5 to 4 m³ and compatibility for excavators from 6 to 70 tonnes, including CAT320, PC1250, ZX1200 and ZX1900, the Monde heavy duty excavator bucket is built for consistent productivity under intensive duty, with no premature stops to replace wear parts.
The design differentiators are cumulative: extra steel plates over the highest-wear zones, a double-radius bottom that reduces friction, and Hardox 400/500, NM360/450 and WH60A steels in higher proportions than on ordinary rock buckets.
The Monde heavy duty excavator bucket is the answer for operators whose total cost per excavated tonne is driven by the frequency of attachment replacement, not by the initial price of the bucket. Key advantages of the Monde heavy duty excavator bucket
• Extra steel plates in the critical zones: the Monde heavy duty excavator bucket adds extra layers of wear steel on the outer bottom, the side corners and the heel, the zones with the highest wear rates in abrasive rock and ore applications. These additional plates double the effective thickness at the critical points compared with a standard rock bucket, directly extending the replacement interval.
• Double-radius bottom design: more clearance at the heel. The double-radius profile of the heavy duty excavator bucket bottom reduces friction of the excavated material against the inner surface during discharge and creates a heel profile with more evacuation clearance. This geometry reduces material build-up when discharging dense materials and ores with fine fractions that tend to adhere to the inner surfaces.
“With the highest wear, a double arch at the base that reduces friction and Hardox 400/500, NM360/450, WH60A steels in larger proportions than in.”
• Hardox 400/500, NM360/450, WH60A steels. The Monde heavy duty excavator bucket can be configured with the highest-performance wear steels available: Hardox 500 (470–530 HB) for extremely abrasive materials, NM450 (420–480 HB) and WH60A for high-impact applications combined with wear. The steel combination is selected according to the specific wear profile of the customer's application.
• 0,5–4 m³ capacity for 6–70 tonne excavators: the Monde heavy duty excavator bucket range covers everything from compact 6-tonne excavators used in low-capacity surface mining, up to ultra-heavy 70-tonne excavators in industrial mining operations and high-capacity quarries. A 4 m³ capacity on a 70-tonne excavator enables significant daily production volumes.
• Premium teeth and adapters: the Monde heavy duty excavator bucket uses tooth systems recognized for reliability in mining and quarry applications with high impact loads. The teeth are replaceable independently, without dismounting the bucket, with parts available in stock at UZINEX Iași.
• Compatible with CAT320, PC1250, ZX1200, ZX1900: the Monde heavy duty excavator bucket is designed with mounting geometries compatible with the reference models in each tonnage class, from the CAT320 (20t class) to the PC1250, ZX1200 and ZX1900 (50–100t class). UZINEX engineers confirm compatibility with your specific excavator model.
• Custom dimensions on request: the Monde heavy duty excavator bucket is available with custom dimensions, widths, heights and openings for applications with specific digging profile requirements or with integration into the production flow of the processing plant.
• 60-month UZINEX warranty: extended coverage with spare parts, teeth and wear plates in stock at Iași, and guaranteed nationwide technical support within 24–48 hours.
Technical specifications: Monde heavy duty excavator bucket
Application dedicated to flows with constant quality requirements.
Equipment configured for medium and large volumes.
Quick adjustment between different orders.
| Parameter | Value |
|---|---|
| Compatible excavators | 6–70 tonnes |
| Capacity | 0,5 m³–4 m³ (model-dependent) |
| Weight | 800–1.400 kg (size-dependent) |
| Structural materials | Q345B, Q460, Hardox 400/500, NM360/450, WH60A |
| Bottom design | Double-radius: extended heel clearance, reduced friction |
| Extra wear plates | Yes: outer bottom, side corners, heel |
| Compatible makes | CAT320, PC1250, ZX1200, ZX1900 and other 6–70t models |
| Customization | Dimensions, widths, heights and openings on request |
| Main applications | Mining, industrial quarries, heavy structural demolition |
The exact steel configuration, capacity and dimensions are selected based on the application and the type of material to be excavated. UZINEX engineers size the heavy duty excavator bucket for the specific conditions of your operation. Free technical consultancy available . When the heavy duty excavator bucket is needed versus the standard rock bucket
The choice between the heavy duty excavator bucket and the standard rock excavator bucket depends on the intensity of wear and the acceptable frequency of parts replacement in the specific context of the operation.
The standard rock bucket is sufficient for moderate-to-high wear applications: limestone and sandstone quarries, earthworks on rocky terrain, concrete demolition. In these applications, the replacement intervals for teeth and bottom plates are predictable and economically acceptable.
The heavy duty excavator bucket becomes the correct solution when wear is extreme and the frequency of parts replacement on the standard bucket becomes prohibitive: mining of ore with high silica and quartz content (Mohs abrasiveness 7+), compact granite and basalt in quarries with continuous production over 2–3 shifts, or recycled materials with metallic components that produce impact in addition to pure abrasive wear.
On excavators fitted with the Monde DEHN quick coupler, switching between the heavy duty excavator bucket and other attachments is done from the cab in under a minute, preserving the flexibility to adapt the attachment to the material encountered on each work face. Main applications for the heavy duty excavator bucket
Surface mining for metallic minerals (iron ore, copper, gold, bauxite) is the application for which the Monde heavy duty excavator bucket is designed as the reference equipment. Metallic ores combine high hardness with extremely abrasive silica and feldspar content, rapidly wearing out any bucket under-specified for wear resistance. The heavy duty excavator bucket with Hardox 500 and additional plates reduces the cost per extracted tonne in these applications compared with frequent replacement cycles of standard buckets.
Compact granite and basalt quarries in the medium and high production class (500–2.000 tonnes/day) require the heavy duty excavator bucket to maintain the planned maintenance intervals. On granite with a compressive strength of 200–250 MPa and a quartz content of 25–30%, wear on a standard rock bucket is 3–5 times faster than on the heavy duty excavator bucket with a Hardox 500 configuration.
Heavy structural demolition of high-strength concrete infrastructure (bridge foundations, concrete dams, hydrotechnical structures) produces combined impact and abrasive-wear loads for which the heavy duty excavator bucket with NM450 or WH60A in the impact zones is the optimal solution in terms of service life.
Handling and loading of dense, abrasive materials (crushed iron ore, metallurgical slag, large-grain crushed stone) at processing stations and on the feed lines of industrial crushers are applications where the heavy duty excavator bucket ensures continuous production without frequent replacements. Frequently asked questions about the heavy duty excavator bucket
Is the heavy duty excavator bucket significantly heavier than the standard rock bucket?
Yes, the additional wear plates of the heavy duty excavator bucket add weight compared with a standard rock bucket of the same capacity. The weight of 800–1.400 kg stated in the specifications includes these plates. UZINEX engineers calculate the exact weight of the chosen model and verify that you do not exceed the available lifting capacity of your excavator at the quotation stage. Does customizing the dimensions of the heavy duty excavator bucket take longer?
A customized heavy duty excavator bucket requires additional lead time compared with the standard catalogue models. The exact lead time depends on the requested modifications and the order volume. UZINEX engineers confirm the delivery time at the quotation stage, together with the technical specifications of the custom configuration. Are the heavy duty excavator bucket teeth compatible with standard systems?
The Monde heavy duty excavator bucket uses tooth systems recognized on the industrial market. UZINEX keeps compatible replacement teeth in stock at Iași for immediate delivery. The exact fixing system of the chosen model is confirmed at the quotation stage. Is the heavy duty excavator bucket eligible for public procurement?
Yes. UZINEX is a member of the Enterprise Europe Network and supplies industrial equipment for projects funded by EU funds and public procurement. Complete technical documentation is provided on request. Leasing options are available on the UZINEX credit and leasing page . Why UZINEX for the heavy duty excavator bucket
The heavy duty excavator bucket is a capital investment with a direct impact on the cost per extracted tonne in intensive operations. The correct steel configuration and the availability of wear parts are the factors that determine the effective payback of the investment.
• 60-month warranty: extended coverage for the Monde heavy duty excavator bucket under continuous industrial operation over 2–3 shifts.
• Custom steel configuration: UZINEX engineers select the optimal combination of Hardox, NM and WH60A for the specific wear profile of your excavated material.
• Transport and installation included: delivery to destination, mounting on the excavator and operator training included in the price of the heavy duty excavator bucket.
• Teeth and wear plates permanently in stock at Iași: the fastest-wearing parts available immediately, with no waiting times that stop production in quarries and mines.
• Customization on request: dimensions, profiles and steel configurations adapted to the specific requirements of your operation.
• Nationwide technical support within 24–48 hours: a network of technicians with national coverage and a guaranteed response time for on-site interventions.
The Monde heavy duty excavator bucket available through UZINEX is the attachment for mining, industrial quarries and heavy structural demolition, with Hardox 400/500, NM360/450, WH60A, a double-radius bottom, additional wear plates, capacities of 0,5–4 m³ for 6–70 tonnes and a 60-month warranty.
