Solar Panel Recycling Line URSTAG

Product code: UZX-384

Decommissioned solar panels hold valuable materials locked inside a laminated structure that is hard to separate.

Aluminum frame removal
By compression; removal rate > 99%; recycling purity > 98%
Glass removal
Hot-knife method; rate 98%; purity 98%; intact reusable glass
Size reduction
Shredder and crusher → granular particles
Screening
Vibrating screens → silicon powder (with silver), copper-plastic mixture
AI takes care
AI manual & maintenance
Transport & commissioning
Free across Romania
SEAP / SICAP
Eligible for public procurement
European funds
PNRR · POR · Just Transition
Industries served

Recommended applications

AIR · WATER CYCLEEVAP19–35kWCOND+55°C-7°CCOP 4.2 · R32 · A+++UZX-HPCREV.ASCALE 1:5DIN 919UNIT: mmUZINEX

Separating the laminate

WEEE · ELECTRONICSU1U2U3FR-4 · 2 LAYER · 1.6 mmUZX-PCBREV.ASCALE 1:5DIN 919UNIT: mmUZINEX

Silicon and silver recovery

CONVEYOR BELTM1M22 400v = 0.5 m/sXYUZX-CNVREV.ASCALE 1:5DIN 919UNIT: mmUZINEX

Solar installers

MAGNETIC SEPARATIONNSFE+→ NON-FERROUS2 000UZX-MAGREV.ASCALE 1:5DIN 919UNIT: mmUZINEX

Copper from cables and conductors

Technical data

Technical specifications

Aluminum frame removalBy compression; removal rate > 99%; recycling purity > 98%
Glass removalHot-knife method; rate 98%; purity 98%; intact reusable glass
Size reductionShredder and crusher → granular particles
ScreeningVibrating screens → silicon powder (with silver), copper-plastic mixture
SortingAir classification, gravity / density separation
CompatibilityCrystalline silicon, thin-film, broken modules, production leftovers
ConfigurationModular, scalable, customizable (complete line or individual machines)
ProcessDismantling → shredding → grinding → advanced separation
Recovered materialValue
Aluminum frame100% recyclable; cuts raw material costs by up to 40%
Silicon powder (with silver)Further purifiable; resale value increases by up to 30%
CopperValuable metal recovered through sorting
GlassHigh quality, directly reusable, no extra processing
EVARecovered encapsulation material
EquipmentRole
Frame removerEfficiently separates aluminum frames by compression
Glass removerExtracts intact glass for direct reuse
ShredderCuts panels into smaller, manageable pieces
GrinderFurther reduces the particle size
Screening and sortingSeparates silicon, copper, plastic into pure fractions
About this equipment

This URSTAG solar panel recycling line links automatic dismantling, shredding, grinding and separation for high-purity glass, silicon, aluminium and EVA. The aluminium frame comes off by compression at over 99%, the glass by hot knife, and the line is modular for solar panel recycling at your scale: take it complete or as separate machines.

Key Advantages of a PV Module Recycling Line

• Frame removal over 99%, the dismantling machine separates the aluminum frame at a rate above 99%, with a recycling purity above 98%.

• Intact, directly reusable glass, glass removal by the hot-knife method recovers high-quality glass (98% rate, 98% purity), ready for direct reuse.

• Wide compatibility, it processes crystalline silicon, thin-film panels, broken modules and production leftovers.

• Advanced separation, air classification, gravity and density separation to segregate copper, silicon and plastic.

• Modular and scalable design, suitable for both industrial-scale operations and small recycling centers, with future upgrades.

• Minimal environmental impact, an efficient process designed for a low ecological footprint.

Specifications and Performance, Solar Panel Recycling Line

ParameterValue
Aluminum frame removalBy compression; removal rate > 99%; recycling purity > 98%
Glass removalHot-knife method; rate 98%; purity 98%; intact reusable glass
Size reductionShredder and crusher → granular particles
ScreeningVibrating screens → silicon powder (with silver), copper-plastic mixture
SortingAir classification, gravity / density separation
CompatibilityCrystalline silicon, thin-film, broken modules, production leftovers
ConfigurationModular, scalable, customizable (complete line or individual machines)
ProcessDismantling → shredding → grinding → advanced separation

Recovered Materials

Recovered materialValue
Aluminum frame100% recyclable; cuts raw material costs by up to 40%
Silicon powder (with silver)Further purifiable; resale value increases by up to 30%
CopperValuable metal recovered through sorting
GlassHigh quality, directly reusable, no extra processing
EVARecovered encapsulation material

Applications for a Waste Solar Panel Recycling System

A solar panel recycling line is intended for electronic waste management operators, specialized recyclers and recycling centers processing end-of-life photovoltaic panels. The wide compatibility, crystalline silicon, thin-film, broken modules and production leftovers, makes it able to process the full variety of solar waste from a single solution, from disassembly to fine sorting.

Decommissioned photovoltaic panels fall under the European regulations on waste electrical and electronic equipment; a solar panel recycling line delivered in Europe is designed in line with the requirements of the WEEE Directive 2012/19/EU. For integration into a complete recycling flow, see also the complete industry solutions.

Maximized material recovery efficiency is the strength of a solar panel recycling line: the silicon powder can be further purified, increasing resale value by up to 30%; the aluminum frames are 100% recyclable, cutting raw material costs by up to 40%; and the high-quality glass can be reused directly, with no extra processing. This valuable recovery turns solar waste into a real and measurable economic resource.

The high-precision automated dismantling of a solar panel recycling line ensures clean recovery: the frame removal machine uses compression to push out and separate the aluminum frame, at a rate above 99% and a recycling purity above 98%. This clean frame separation, in the very first stage, isolates the aluminum as a pure material and prepares the panel for the subsequent processing stages.

Intact glass recovery is a distinctive advantage of a solar panel recycling line: the glass layer is removed by the hot-knife method, which exposes the core components of the cell and the backsheet, recovering high-quality glass at a 98% rate and 98% purity. The intact glass obtained this way can be reused directly, with no extra processing, maximizing the recovered value.

The advanced separation system of a solar panel recycling line ensures pure final products: after size reduction, the vibrating screens separate the fractions, silicon powder with silver, copper-plastic mixture, and the sorting system uses air classification, gravity and density separation to segregate copper, silicon and plastic. This staged sorting produces clean, well-defined final materials, each ready for recovery and resale on the secondary raw-material market.

Core Equipment

EquipmentRole
Frame removerEfficiently separates aluminum frames by compression
Glass removerExtracts intact glass for direct reuse
ShredderCuts panels into smaller, manageable pieces
GrinderFurther reduces the particle size
Screening and sortingSeparates silicon, copper, plastic into pure fractions

The Recycling Process

1. The frame removal machine pushes out by compression and separates the aluminum frame (rate > 99%).

2. The glass layer is removed by the hot-knife method, exposing the cells and the backsheet (rate 98%).

3. The crusher shreds and pulverizes the cells into granular particles.

4. The screening equipment, with vibrating screens, separates the fractions: silicon powder with silver and copper-plastic mixture.

5. The sorting system segregates copper, silicon and plastic through air classification and density separation.

6. The final materials, frame, copper, silicon powder, glass and EVA, are collected separately.

The entire flow is automated, from dismantling to fine sorting. A solar panel recycling line thus produces high-purity final materials, glass, silicon, aluminum, copper and EVA, ready to be reintroduced into the economic cycle, with consistently high efficiency and minimal environmental impact.

What Uzinex provides

• Delivery, installation and commissioning, with operator training on your own production.

• 60-month warranty and service with on-site response in under 24 hours in Romania (24–72 hours in other countries).

• Technical documentation for EU-funded, PNRR and public procurement projects.
