Truck and OTR Tire Shredder URSTAG

Product code: UZX-307

Heavy-duty shredder engineered for steel-reinforced passenger car, truck and OTR tires.

Machine type
Twin-shaft truck tire shredder, high torque and low speed
Feedstock
Car, truck, and OTR tires (OTR with pre-cutting)
Chip size
50–150 mm, depending on the screen
Knives
Removable discs, bolted on, individually replaceable
AI takes care
AI manual & maintenance
Transport & commissioning
Free across Romania
SEAP / SICAP
Eligible for public procurement
European funds
PNRR · POR · Just Transition
Industries served

Recommended applications

TIRE RECYCLINGCRUMB3-5 mmUZX-TIRREV.ASCALE 1:5DIN 919UNIT: mmUZINEX

Truck tires

DIGGING · LEVELINGP13 200 mmUZX-EXBREV.ASCALE 1:5DIN 919UNIT: mmUZINEX

OTR mining tires

CRAWLER · 4 DRIVE WHEELSL 9800–25 m/min · IP68UZX-CRWREV.ASCALE 1:5DIN 919UNIT: mmUZINEX

Quarries and mines

TWIN-SHAFT SHREDDINGØ 802 × 22 kW · 25 RPMUZX-SHRREV.ASCALE 1:5DIN 919UNIT: mmUZINEX

Large recycling centres

Technical data

Technical specifications

Machine typeTwin-shaft truck tire shredder, high torque and low speed
FeedstockCar, truck, and OTR tires (OTR with pre-cutting)
Chip size50–150 mm, depending on the screen
KnivesRemovable discs, bolted on, individually replaceable
Jam protectionAutomatic direction reversal on overload
OTR pre-cutting"Crocodile" type shear for very large tires
CalibrationInterchangeable lower screen
ComponentsWith CE marking where applicable
CapacityConfigurable per project
Accepted materialNotes
Truck tiresThe main feedstock, heavily reinforced with steel
Car tiresDirect processing, no pre-cutting
OTR / machinery tiresMandatory pre-cutting for large diameters
Agricultural tiresDepending on size, with pre-cutting
About this equipment

This URSTAG OTR tire shredder is built for the thick, heavily steel-reinforced rubber of heavy tires. A double-shaft tire shredder with high torque and low speed, it tears car, truck and equipment tires into 50–150 mm chips, while very large OTR tires are pre-cut first.

Key Advantages for Shredding Car and Truck Tires

• Built for heavy tires, a truck tire shredder has shafts, knives, and a housing sized for the thick, heavily reinforced tires of commercial vehicles.

• Wide tire range, it processes car and truck tires and, with pre-cutting, OTR tires from construction and agricultural machinery.

• High torque, low speed, the high force at low rpm tears steel-reinforced rubber without jamming and with reduced knife wear.

• Removable knives, the cutting discs are bolted on and replaced individually, keeping the maintenance cost under control.

• Automatic reversal on jam, on overload, the shafts reverse direction, release the material, and protect the transmission.

• Wide feeding mouth, it accepts whole truck tires and large pre-cut pieces, reducing handling at the inlet.

• Calibration screen, the lower screen controls the chip size, which you adapt to the next stage.

• Directly sellable chips, the resulting chips sell as TDF or go toward rasping and granulation for finer fractions.

Technical Specifications, Truck Tire Shredder

ParameterValue
Machine typeTwin-shaft truck tire shredder, high torque and low speed
FeedstockCar, truck, and OTR tires (OTR with pre-cutting)
Chip size50–150 mm, depending on the screen
KnivesRemovable discs, bolted on, individually replaceable
Jam protectionAutomatic direction reversal on overload
OTR pre-cutting"Crocodile" type shear for very large tires
CalibrationInterchangeable lower screen
ComponentsWith CE marking where applicable
CapacityConfigurable per project

Applications and Industries for OTR and Commercial Tires

A truck tire shredder is the right machine for operators who receive mixed tire flows dominated by commercial ones. Truck and OTR tires are the most problematic to store, take up a lot of volume, and are hard to handle whole. A robust shredder reduces them to chips that are easy to transport and process, freeing up valuable space and opening the way to material and energy recovery.

Industrial shredding equipment must meet the safety requirements of the European Union; a truck tire shredder delivered in Europe is compliant with the requirements of Directive 2006/42/EC on machinery.

The chips produced by a truck tire shredder go as TDF to cement plants, burn cleanly, and can replace a good part of the expensive fossil fuels, or they can be sent further toward rasping and granulation. For an operator working with fleets, truck service centers, mines, or quarries, the ability to process end-of-life heavy tires on the spot turns a disposal cost into a source of feedstock.

The volume of end-of-life commercial tires is constant and concentrated around fleets, machinery yards, and mining operations. This means a predictable supply source for a properly sized truck tire shredder, often right at the place where the waste is generated, which further reduces logistics costs and makes on-site shredding an attractive solution.

Compatible Materials

A truck tire shredder is designed for the hardest and bulkiest tires. Huge OTR tires are pre-cut before feeding, and the knives and screen are chosen according to the type of tire and the desired final size. The robust construction allows it to move from the car tire to the truck tire without problems.

Accepted materialNotes
Truck tiresThe main feedstock, heavily reinforced with steel
Car tiresDirect processing, no pre-cutting
OTR / machinery tiresMandatory pre-cutting for large diameters
Agricultural tiresDepending on size, with pre-cutting

How It Works

The flow through a truck tire shredder is robust and easy to automate, designed for heavy tires:

1. The truck and car tires are fed into the wide mouth, manually or with a hydraulic grab.

2. The very large OTR tires are pre-cut with the "crocodile" type shear before shredding.

3. The two counter-rotating shafts grip and pull the tire between the interlocking cutting discs.

4. The high torque and low speed tear the reinforced rubber without clogging and without damaging vibration.

5. On overload, the system automatically reverses the direction of the shafts and resumes cutting.

6. The lower screen calibrates the chips to 50–150 mm and discharges them onto a belt, ready for processing.

Oversized material is recirculated between the knives until it reaches the required size. A continuously monitored truck tire shredder maintains a consistent throughput and quickly brings new operators to stable results, a real advantage in plants with staff turnover. The control system flags overloads and allows planned maintenance without long production stoppages.

What Uzinex provides

• Delivery, installation and commissioning, with operator training on your own production.

• 60-month warranty and service with on-site response in under 24 hours in Romania (24–72 hours in other countries).

• Technical documentation for EU-funded, PNRR and public procurement projects.
